Shelf fittings for removable cabinet shelves, including cam-style supports and straight metal pin assemblies. Straight-body references are shown in 6, 8 and 9 mm families; the cam fittings use their own drilling layout.
English PDF · 16 pages · 12 selected families
Match pin, sleeve, shelf thickness and hole layout. Load capacity depends on the complete shelf and cabinet assembly; request project-specific confirmation.
Download Hardware CatalogShelf fittings for removable cabinet shelves, including cam-style supports and straight metal pin assemblies. Straight-body references are shown in 6, 8 and 9 mm families; the cam fittings use their own drilling layout.
Confirm fit and finish on a sample before a bulk order. Request the applicable material, dimensional, load, cycle or corrosion test documents for the chosen model and destination. This selection catalog is not a test report or certification.
Send the inquiry reference, marked photo or drawing, dimensions, material or finish, quantity per item and destination. Include board thickness and mounting details where relevant. JINYOU confirms price, MOQ, packing and lead time for the selected items.
Request a QuoteYes. List each reference and quantity separately. Sales will check item availability, matching components, packing and shipment options; a mixed inquiry does not imply one common MOQ or immediate stock.
Cam locks and connecting bolts for knock-down cabinets, wardrobes and panel furniture. The catalog shows cam families for 10, 12 and 15 mm drilling, with several bolt and sleeve designs. Components must be selected as a compatible set.
Plastic pull handles for cabinet doors and drawers. The selected black handle has a 96 mm fixing-center reference, while the decorative range includes several shapes and colors. Use a sample to match the furniture finish.
Threaded leveling feet for furniture and cabinet bases. The selection shows M6, M8 and M10 thread families with different round pads and finishes. Choose the stud and base together to suit the furniture frame.
