JINYOU New Material is a leading PVC edge banding manufacturer based in Xiaoshan, Hangzhou, Zhejiang — China's premier polymer materials hub. We produce 200+ colors and 12 surface finishes, supplying furniture factories, cabinetry brands, and distributors in 50+ countries.
From furniture-grade solid colors to photorealistic wood grains and architectural specialty finishes — manufactured to consistent thickness and color tolerances.
Pure white, pure black, grey, beige, cream, and 180+ custom solid colors. Available in gloss, matte, soft-touch, and anti-fingerprint surfaces. Thickness 0.4mm–3mm, width 19mm–54mm. Pantone matching supported. Compatible with all edge banding machines.
View Solid Color Range →
Oak, walnut, teak, wenge, maple, cherry, pine, and 100+ natural wood species. 3D embossed synchronized texture for board-to-edge grain matching. Also available: marble, stone, and concrete pattern edge banding for commercial and architectural applications.
View Wood Grain Range →
Mirror-like finish from 85–95+ GU. Acrylic-look grade available for a deep translucent mirror effect at PVC cost. Matched to high gloss melamine boards from Egger, Kronospan, and others. For kitchens, wardrobes, and premium furniture.
View High Gloss Range →
Ultra-low gloss under 5 GU with velvet-like texture and anti-fingerprint surface. Matched to Egger Feelwood, Kronospan Elegance, and other ultra-matte board collections. Zero light reflection for premium modern interiors.
View Super Matte Range →
EVA hot melt adhesive pre-applied. Activate with a household iron at 140–160°C — no edge banding machine required. Available in all colors, wood grain, matte, and gloss finishes. Ideal for DIY, repair, and small workshops.
View Pre-Glued Range →Standard factory specifications. All dimensions are customizable — contact us with your exact requirements.
| Thickness | 0.4 / 0.45 / 0.5 / 1.0 / 1.5 / 2.0 / 3.0 mm |
| Width | 19 / 22 / 25 / 28 / 32 / 35 / 42 / 54 mm |
| Roll Length | 50m / 100m / 200m (standard); custom on request |
| Core Inner Diameter | 70mm (standard) / 150mm (jumbo) |
| Colors Available | 200+ stock colors + custom Pantone matching |
| Base Material | Virgin PVC resin (REACH compliant) |
| Surface Finish | Gloss / Matte / Soft-touch / Embossed |
| Back Color | Grey (standard) / Custom color available |
| Glue Layer | Optional EVA pre-coat available |
| Temperature Resistance | –15°C to +60°C (standard use) |
| Edge Banders | Homag, Biesse, SCM, IMA, Brandt, Holzher |
| Application Temp. | 160–200°C (EVA glue) / 120–150°C (PUR) |
| Feed Speed | Up to 30 m/min |
| Glue Consumption | 100–150 g/m² (standard) |
| Manual Application | Pre-glued tape available |
| Chemical Safety | REACH, RoHS compliant |
| Quality System | ISO 9001:2015 |
| Formaldehyde | E0 / E1 emission levels |
| Flammability | GB 8624 Class B available |
| Custom Testing | SGS / Intertek on request |
Established in Xiaoshan, Hangzhou — China's polymer manufacturing heartland — JINYOU combines 20+ years of production expertise with direct factory pricing and responsive export service.
No middlemen, no trading company markup. Buy directly from the manufacturer and save 15–30% versus distributor pricing. Transparent FOB, CIF, and DDP quotations available.
The widest solid-color and wood-grain range in Xiaoshan. Custom Pantone and RAL matching available. New color development from 2,000 meters. Sample lead time: 7 business days.
State-of-the-art calendar and extrusion lines. Thickness tolerance ±0.02mm. Color consistency within ΔE<1.5 across batches. Every roll tracked with batch and production date.
Active exports to the Middle East, Europe, Southeast Asia, Australia, and the Americas. Familiar with all import requirements, documentation, and shipping terms.
Standard MOQ: 500 meters per color. Mixed-color containers accepted. Sample packs available for new customers — free shipping via DHL or FedEx express within 3–5 days.
Full OEM service: custom core color, branded packaging, exclusive color development, and private label rolls. Trusted by major furniture brands across Europe and the Middle East.
JINYOU PVC edge banding is specified by furniture manufacturers, cabinetry brands, kitchen studios, and panel processors worldwide.
Wardrobes, beds, TV units, shelving, and living room furniture requiring durable, scratch-resistant edge protection.
Cabinet doors, drawer fronts, and kitchen carcasses. High-gloss and matte finishes popular with European kitchen brands.
Desks, storage units, partitions, and modular office systems requiring clean, professional edge finishes.
Hotel furniture, retail displays, restaurant seating, and hospitality fit-out projects requiring volume supply and consistent color.
Ready-to-assemble flat-pack furniture requiring tight tolerances, consistent color, and high volume output for e-commerce and retail.
MDF, particleboard, plywood, and MFC board manufacturers requiring high-speed edge banding at up to 30m/min feed rates.
Caravan and RV interior furniture, boat cabinetry, and vehicle fit-out requiring flexible, moisture-resistant edge banding.
Custom joinery, bespoke cabinetry, and interior fit-out projects requiring specialist finishes like marble, metallic, and acrylic.
Match four parameters before placing an order — thickness, color, finish, and width. Getting all four right means zero visible joint and zero production rejects.
0.4–0.5mm for 16–18mm standard panels. 1mm for 25mm+ or heavy-use. 2–3mm for premium furniture and radius edges. Laser 0.3mm for zero-joint finish lines.
Always compare physical samples under both daylight and fluorescent light. Request a gloss reading (GU value) alongside color to ensure gloss levels match your board.
Match finish to board: super-matte (<5 GU) for Feelwood/Elegance collections; high-gloss (85–95+ GU) for mirror panels; wood-grain emboss synchronized to grain direction.
Standard 19mm for 18mm boards (1mm overhang each side). 22mm for 25mm boards. 25–54mm for thick panels and plywood. Overhang is trimmed off after application.
Need help selecting? Read our complete PVC Edge Banding Buying Guide →
Five tests you can perform on any sample roll — no lab equipment required — to verify material quality before placing a full production order.
Measure thickness at 5 points across the roll width with a micrometer. Variation should be ≤±0.02mm. High variation causes uneven glue application and visible ridges after trimming.
Compare a strip from the roll start with a strip from the end. Color difference should be ΔE<1.5 under standard illuminant D65. JINYOU measures and records ΔE for every production batch.
Run your fingertip along the surface — there should be no ripples, bubbles, or texture variation. Tilt under a strong light to check for streaks or uneven coating that will show under gloss paint.
The glue side should feel slightly rough — not smooth or oily. A smooth back means poor adhesive grip. Rub the back with your thumb: no color or material should transfer onto your skin.
Bend a 0.5mm strip 180° around a 10mm radius. It should flex without cracking or whitening. Brittle bending means under-plasticized PVC — a sign of cost-cutting that will cause production failures in cold workshops.
Every JINYOU production batch includes: thickness report, color ΔE measurement, adhesion test, and surface defect inspection. Test reports available upon request. ISO 9001:2015 certified.
Having production issues? See our complete edge banding troubleshooting guide →
PVC edge banding is a thin strip of polyvinyl chloride material applied to the exposed raw edges of panel boards — MDF, particleboard, plywood, and MFC. It protects edges from moisture, chipping, and wear, and provides a decorative finish matching the board surface. Used in kitchen cabinets, wardrobes, office furniture, retail shelving, and RTA flat-pack furniture worldwide.
PVC is the most cost-effective, with the widest color range and universal machine compatibility. ABS (acrylonitrile butadiene styrene) is more flexible at low temperatures and carries European eco certifications — preferred in EU markets. Laser edge banding has a special functional layer that bonds with a laser beam instead of hot melt adhesive, producing a completely seamless zero-joint finish — specified for premium kitchen and wardrobe production lines using Homag or Biesse laser machines.
The PVC material itself does not absorb water. However, the adhesive joint can be vulnerable to prolonged moisture — particularly with standard EVA hot melt. For kitchen, bathroom, and outdoor applications, specify PUR (polyurethane reactive) hot melt adhesive, which forms a chemically cured, waterproof bond. JINYOU supplies both EVA and PUR adhesive grades to pair with our edge banding.
0.4–0.5mm for standard 16–18mm residential furniture panels — the most widely used range. 1mm for commercial furniture and 25mm+ thick panels. 2–3mm for high-end furniture and surfaces requiring a substantial edge feel. Laser edge (0.3mm functional layer) for zero-joint lines. For curved profiles with radius under 10mm, use 0.4–0.5mm only — thicker grades will crack.
Yes. JINYOU maintains color matches for major European board brands including Egger, Kronospan, PFLEIDERER, Sonae, and Unilin. Popular matches include Egger W980 Oak, H1334 Gladstone Oak, U961 Anthracite, and many Kronospan standard decors. Contact us with your board reference — we confirm the available match or develop a custom one within 7–10 business days.
For automatic machines: EVA hot melt at 160–200°C for standard furniture; PUR hot melt at 110–130°C for moisture-resistant and outdoor applications. For pre-glued iron-on tape: activate with a household iron at 140–160°C — no machine required. JINYOU manufactures both EVA and PUR adhesive grades specifically formulated for PVC edge banding. See our hot melt adhesive page for specifications.
Store rolls upright (standing on their edge) — never flat. Temperature: 18–25°C. Humidity: 40–60% RH. Avoid direct sunlight and heat sources. Under correct storage, PVC edge banding is usable for 2+ years from production date. Rolls stored flat develop a permanent curve that causes wavy edges after application — a common production defect from improper storage.
We manufacture PVC edge banding from 0.4mm to 3mm. Standard stock thicknesses: 0.4mm, 0.45mm, 0.5mm, 1mm, 1.5mm, 2mm, and 3mm. Thickness tolerance ±0.02mm. Custom thickness available for orders above 5,000 meters per thickness.
Standard MOQ is 500 meters per color for stock products. No minimum for sample rolls (1–2 meters per color, free). Custom Pantone-matched colors: MOQ 2,000–5,000 meters. Mixed-SKU container orders accepted with a minimum of 500 meters per color.
Yes. JINYOU PVC edge banding is formulated for all major edge banding machines: Homag, Biesse, SCM, IMA, Brandt, and Holzher. Feeds consistently at up to 30 m/min, optimized for minimal glue consumption and clean post-trim finishing.
Yes. We offer Pantone and RAL solid color matching, and can develop custom wood grain or pattern designs for orders above 10,000 meters per color. Provide a color chip, physical sample, or color code — sample delivery within 7–10 business days.
Stock colors: 3–5 business days from payment. Custom colors and large orders: 15–25 business days production. Sea freight: Middle East 18–25 days; Europe 25–35 days; North America 30–40 days from Ningbo or Shanghai.
The most common causes: glue temperature too low (should be 170–190°C for EVA — always verify with an infrared thermometer, not the machine gauge), contaminated board surface (dust or silicone residue), or wrong adhesive grade for your board type. See our complete edge banding troubleshooting guide for all 10 common defects and their fixes.
Yes. JINYOU provides full OEM and private label: custom back-side core color, branded packaging, custom cardboard cores, exclusive color lock-in, and private label rolls. Minimum for OEM programs: 5,000 meters per color per month. Contact us for details.
