JINYOU New Material manufactures PVC co-extrusion board with a hard co-extruded skin layer over a lightweight foam core. Superior hardness, screw-holding capacity, and paintability. Thicknesses 3–25mm, sheet sizes 1220×2440mm and 2050×3050mm. Supplied to furniture, cabinet, marine, and construction industries in 50+ countries.
Hard-skin co-extruded PVC boards combining a rigid foam core with a dense, smooth outer layer — delivering furniture-grade hardness at a fraction of solid PVC weight.
Hard skin on one face, foam core exposed on reverse. Ideal for cabinet backs and panels where only one surface is visible. Lighter and more cost-effective for interior applications.
Request Sample →
Hard co-extruded skin on both faces. Maximum rigidity, scratch resistance, and screw-holding capacity. Premium choice for furniture doors, kitchen cabinets, and marine panels.
Request Sample →
Available in white, black, grey, and 20+ custom colors through the skin layer. No painting required for standard colors. OEM colors available from 500 sheets for branded interiors.
Request Sample →Standard factory specifications. All dimensions customizable — contact us with your exact requirements.
| Thickness | 3 / 5 / 8 / 10 / 12 / 15 / 18 / 20 / 25 mm |
| Sheet Size | 1220×2440mm / 2050×3050mm |
| Skin Thickness | 0.3–0.8mm per side |
| Colors | White, Black, Grey + 20 custom |
| Surface | Glossy / Matte / Textured |
| Core Density | 0.45–0.65 g/cm³ |
| Surface Hardness | Shore D 75–85 |
| Tensile Strength | ≥22 MPa |
| Water Absorption | <0.3% |
| Screw Pull-Out | ≥800 N |
| Cutting | Circular saw, CNC router, table saw |
| Painting | PU, acrylic, 2K paints — excellent adhesion |
| Lamination | PVC film, veneer, HPL — direct bonding |
| Joinery | Screws, dowels, cam locks, adhesive |
| Thermoforming | Not recommended (rigid skin) |
| Chemical Safety | REACH, RoHS compliant |
| Quality System | ISO 9001:2015 |
| Flame Retardancy | B1 / B2 grade available |
| Formaldehyde | Zero formaldehyde emission |
| Custom Testing | SGS / Intertek on request |
JINYOU combines factory-direct pricing with consistent co-extrusion quality for buyers who need furniture-grade surface performance at competitive cost.
Buy direct from the co-extrusion manufacturing line. No middlemen. Save 20–35% vs. distributor pricing. Transparent FOB, CIF, and DDP quotations.
Shore D 75–85 hard skin vs. Shore D 55–65 for standard free foam. Resists dents, scratches, and surface damage during handling and installation.
Pull-out force ≥800N enables reliable screw, dowel, and cam-lock joinery — essential for furniture and cabinet construction without inserts.
Water absorption <0.3%. Zero organic material means no termite, mold, or rot risk. Ideal for kitchens, bathrooms, marine environments.
Hard skin bonds directly with PU, acrylic, and 2K paints. Accepts PVC film, paper laminate, and HPL without primer in most applications.
Active exports to Middle East, Europe, Southeast Asia, and Americas. Familiar with all standard import documentation and Incoterms.
Co-extrusion board is the preferred substrate for applications requiring hard surface performance, moisture resistance, and lightweight construction.
Wardrobe interiors, shelving, side panels, and cabinet carcasses requiring hard, stable surfaces.
Kitchen cabinet doors, drawer fronts, and worktop surrounds. Moisture-proof and easy to clean.
Vanity units, shower enclosures, and bathroom furniture panels. Fully waterproof construction.
Boat and yacht cabin linings, galley panels, and marine furniture where weight and moisture resistance are critical.
Interior wall cladding, clean room panels, and partition systems requiring a hard, smooth, paint-ready substrate.
RV and caravan interior panels, bus ceiling linings, and vehicle partition boards.
Trade show displays, retail fixtures, and museum installations requiring rigid, paintable panels.
Office partitions, reception desks, retail counters, and commercial furniture requiring durable, hard-wearing panels.
Co-extrusion board has a dense, hard PVC skin co-extruded onto the foam core during manufacturing. This gives Shore D 75–85 hardness vs. Shore D 55–65 for free-foam PVC. The result is better screw retention, scratch resistance, and paint adhesion.
We manufacture co-extrusion board from 3mm to 25mm. Common stock thicknesses include 5, 8, 10, 12, 15, and 18mm. Custom thicknesses are available for large orders (MOQ applies).
Standard MOQ is 1,000 m² per color/thickness. Trial orders accepted from 200 m². Custom colors have a MOQ of 2,000 m².
Yes. The hard skin surface offers excellent adhesion for PU, acrylic, and 2K paints without primer. Surface preparation with light sanding (180 grit) is recommended for best results.
Stock items ship within 5–7 business days. Custom orders take 15–25 days. Sea freight from Ningbo to Middle East approximately 20 days; to Europe approximately 30 days.
